Monitor Audio Anthra W10

Monitor Audio Anthra W10

Deep, Controlled Bass
It’s not easy making things simple. It takes effort; but it is worth it. The Anthra Subwoofer Series embraces simplicity, with three clearly defined, high-performance subwoofers that are designed to deliver deep, controlled bass with an intuitive user-experience. That’s it. It’s simplicity at its best.

Anthra W10

The W10 is the most compact model within the Anthra subwoofer series. It features a 10” (25 cm) Rigid Surface Technology II (RST II) C-CAM high-excursion driver powered by a Class-D 500 Watt amplifier, housed within a comprehensively internally braced, sealed-box cabinet.

Engineered to deliver deep, agile bass in small to mid-sized spaces, the Anthra W10 subwoofer features a 500 Watt Class-D amplifier driving a 10” (25 cm) Rigid Surface Technology II (RST II) C-CAM high-excursion driver. The W10 can be used on its own or linked with up to three other Anthra subwoofers for a truly immersive, ultra-dynamic listening experience.

A full-colour LCD display and rotatory dial is located on the back panel, to allow for basic subwoofer setup and EQ preset selection, while advanced features including DSP configuration and multi-sub connectivity setup are available via the MaestroUnite app.

Key Features
1 x 10” (25cm) Rigid Surface Technology II (RST II) and ceramic-coated aluminium magnesium (C-CAM) high-excursion driver for super-clean performance
1 x 500 Watt Class-D amplifier ensures that the driver is working to its optimum performance level, no matter what the volume
Massive motor assembles and longer round-wound voice coils, which are dual layered and made of copper-coated aluminium wire (CCAW) for precise control at extreme low frequencies.
2 inch full-colour LCD display screen with rotary dial for menu selection and basic setup
RCA inputs (left/right. The left Input is LFE)
RCA outputs allows daisy chain of up to 4 Anthra subwoofers
XLR inputs for professional installation connectivity option
XLR outputs allows daisy chain of up to four Anthra subwoofers
Available in Gloss Black and Satin White finishes
MaestroUnite Setup for Monitor Audio Anthra Subwoofers allows a user complete bespoke setup. Available to download from the App Store and Google Play.

Monitor Audio Anthra W10 specifications

System Format – Active – Sealed Cabinet
Drive Unit Complement – 1x 10″ (254 mm) High Linear-Excusion Triple Suspension Driver
Amplifier Classification – High-Efficiency Class-D
Lower Frequency Limit – -6dB @17Hz
Upper Frequency Limit – (LPF Off) -6dB @400Hz
Driver Excursion (pk-pk) – 50 mm
DSP – 28 Bit 50 MIPS Configurable through MaestroUnite
Analogue Digital Conversion – Autoranging Input which combines a 10Vrms maximum input with low signal to noise for small signals
Amplifier Output Power, 240Vac – Instantaneous: 500 W*, Continuous short-term: 425 W**
Amplifier Output Power, 120Vac – Instantaneous: 450 W – Continuous short-term: 390 W
LED UI Control – Brightness, On-Off
Phase Control – 0-360 Degrees measured at LPF Crossover
Low Pass Filter – 20-200Hz LPF with Roll off Adjustable from -3 to -48dB/Oct
Custom EQ – Configurable through MaestroUnite;3 pre-defined EQ curves plus 3 custom EQ curves each with 8 band custom EQ supporting (Peaking, High Shelf, Low Shelf, High Pass)
Volume Level – Wide adjustable input gain to allow maximum output from a wide range of input signals
Inputs
Stereo Unbalanced RCA (or mono/LFE using only connector marked LFE)Mono/LFE Balanced XLR
Outputs
Stereo unbalanced outputs with unbuffered throughput from RCA Inputs
Mono/LFE Balaned XLR outputs with unbuffered throughput from XLR Input
Mains Input Voltage – Universal Mains, 85-265VAC
External Dimensions (without feet) (HxWxD) – 321 x 321 x 321 mm
Power Consumption – 120 W
Cabinet Construction – Braced 18 mm thick MDF with 36 mm front baffle
Grille – Cloth covered magnetically attached Grilles
Weight – 20.06 kg (44 lb 1 oz)
* Maximum RMS output for an instantaneous signal
** Sinewave for 10 seconds
