Lumin U2 Mini

Lumin U2 Mini

Network Music Transport

Why LUMIN U2 MINI?

The product that first launched their all-new processing system, LUMIN U2 Mini takes all of their latest software features and packs them into a new all-aluminium compact chassis.

Capable of upsampling and downsampling all the way from 44.1kHz to 384kHz/DSD256 and supporting playback of DSD512, LUMIN U2 MINI is the perfect streaming partner for your DAC.

Lumin U2 Mini main features

• Transport-only LUMIN for combination with an external DAC
• The first LUMIN to feature our all-new processing system
• New all-aluminium compact chassis
• Faster processor provides greater resampling flexibility – upsampling and downsampling to every supported format up to DSD256/PCM384 to hit your DAC’s sweetspot
• Increased capacity for future updates
• New surface finish taken from the high-end P1
• Quad native clock system for precision timing
• 5 types of digital audio output including USB
• MQA Decoding
• Roon Ready
• Leedh Processing volume control

Builds on the massive success of U1 Mini

Completely new processing hardware and software deliver improved features and increased resampling flexibility while retaining all the musicality that was noted in so many outstanding U1 Mini reviews.

Key hardware features carried over from U1 Mini include the quad clocking system and 5 different digital outputs with USB now capable of up to DSD512!

The new model is also finished in a new silky surfacing process taken from our high-end P1 that is less susceptible to finger marks and easier to clean.

All the usual LUMIN refinements

• From MQA to DSD, FLAC to WAV, LUMIN can play all the high-resolution formats you could ever want
• Native support for TIDAL, Qobuz, Spotify and AirPlay, giving you access to tens of millions of songs
• The unique and intuitive LUMIN App described as “fantastically intuitive and easy to use” by What Hi-Fi
• LUMIN programme of continuous development that has seen Apple Silicon Mac support, TIDAL Connect, FLAC Lossless Radio and TIDAL Suggested/Related tracks added in 2021 alone.

Lumin U2 MINI Specification

Network playback:

• Up to DSD512
• Up to 768kHz, 16–32-bit, Stereo
• MQA Decoding

Upsampling rates & bit depths:

• DSD256 upsampling option for all files
• PCM 384kHz upsampling option for all files

Digital Output Stage:

• USB: Native DSD512 support PCM 44.1–768kHz, 16–32-bit, Stereo
• Optical, Coaxial RCA, Coaxial BNC & AES/EBU: DSD64 (DoP64, DSD over PCM) PCM 44.1kHz–192kHz, 16–24-bit

Power Supply: Internal shielded 100–240V AC auto-ranging

Physical: Finish: Black anodised aluminium, Raw anodised aluminium

Size and Weight: 300mm (W), 244mm (D), 60mm (H), 2.5kg

Packaging: 470mm (W), 340mm (D), 170mm (H), 4.5kg
